Rivet Nut M6 size with a Large Flange, Left Hand Thread in Stainless Steel 304.
Also known as a Rivnut or Nutsert.
For 4.2 to 6.6mm thick steel. The more common rivnuts are for thinner steel posts.
Matching Right Hand Thread Rivet Nuts also available. Often used with M6 Swage Stud Terminals Left Hand Thread.
Creates a neat, slimline inner fixing method for wire rope runs between metal posts.
Specifications
More Information
Product Material
Stainless Steel 304
Swaging System
Hydraulic Swaging
Wire Rope Diameter
3.2mm
Product Specifications
M6 Rivet Nut
Stainless Steel 304
for 4.2 to 6.6mm thick steel
Large Flange
Left Hand Thread
Total Length: 18mm
Outer Flange Diameter: 12.6mm
Rivnut Shaft Diameter: 9.5mm
Flange thickness: 0.8mm
Brand
ProRig
Stock Availability
In Stock
Bulky item
No
Compatible With
Known Incompatible Products
We haven't added anything here yet.
For technical requirements where you are unsure what products are and are not compatible please Contact Us.
Please note these are general Compatibilities/Incompatibilities, we cannot provide advice as to whether these components will meet the technical/structural requirements of your project. For this type of information you will need a builder, engineer or other qualified professional to assess your site and needs.
Incompatible With
Known Incompatible Products
We haven't added anything here yet.
For technical requirements where you are unsure what products are and are not compatible please Contact Us.
Please note these are general Compatibilities/Incompatibilities, we cannot provide advice as to whether these components will meet the technical/structural requirements of your project. For this type of information you will need a builder, engineer or other qualified professional to assess your site and needs.
