Espaliex Trellis Wire Hub 42mm for Espalier/Green Wall Stainless Steel 316 with Screw
From$7.90
To$7.96
Secure your espalier / trellis wire with this discreet and strong Espaliex 42mm Wire Trellis Hub. This fitting doesn't require any special crimping or swaging tools. Suits up to 3.2mm wire. Self Tapping Screws included.
Espaliex Wire Trellis Hubs are specifically designed for running trellis wire along walls and other vertical surfaces, to help your vines, creepers and trees to grow.
Secure your espalier / trellis wire with this discreet and strong Espaliex 42mm Wire Trellis Hub.
Successful installation is quite simple and doesn't require any special crimping or swaging tools. First, to secure the fitting onto the wall or post, you'll need a 75mm #2 Phillips drive bit or a screwdriver. Drive the self-tapping screws provided through the internal shaft and through the base opening into the wall mounting point.
To install the wire, thread the wire through the holes, and then secure the wire in place by twisting the grub screw down using a 6mm allen key. Repeat the process above and pull the wire taught using a pair of pliers. Add end caps to protect the wire from fraying and pricking fingers.
Suits 3.2mm wire.
Self Tapping Screw 10G x 1 3/4" (45mm) SS304 included. Pre-drilling essential when fixing into hardwood.
Optionally available wallplug for fixing into masonry/brick.
Specifications
More Information
Product Material
Stainless Steel 316
Wire Rope Diameter
3.2mm
Product Specifications
Product Specifications:
Length: 42mm
Suits Wire: Up to 3.2mm
Stainless Steel 316
Satin Finish
6mm Hex Drive (Allen Key)
Dimensions:
Overall Length: 42mm
Length to 1st Wire: 27mm
Length to 2nd Wire: 30mm
Outer Diam.: 20mm
Self Tapping Screw:
10 Gauge
1 3/4" (45mm) Length
Countersunk Head
Stainless Steel 304
#2 Phillips Drive
Stock Availability
In Stock
Bulky item
No
Compatible With
Known Incompatible Products
We haven't added anything here yet.
For technical requirements where you are unsure what products are and are not compatible please Contact Us.
Please note these are general Compatibilities/Incompatibilities, we cannot provide advice as to whether these components will meet the technical/structural requirements of your project. For this type of information you will need a builder, engineer or other qualified professional to assess your site and needs.
Incompatible With
Known Incompatible Products
We haven't added anything here yet.
For technical requirements where you are unsure what products are and are not compatible please Contact Us.
Please note these are general Compatibilities/Incompatibilities, we cannot provide advice as to whether these components will meet the technical/structural requirements of your project. For this type of information you will need a builder, engineer or other qualified professional to assess your site and needs.
4.7 rating from 35 reviews
